| Housing colour | grey | ||
| Material cable sheath | PVC | ||
| Note on materials | RoHS-compliant | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Note on degree of protection | In assembled state | ||
| Cable structure | Shielded | ||
| Cable characteristic | Standard | ||
| Current rating at 40°C | 1 A | ||
| Electrical connection 2, connection pattern | 00995642 | ||
| Electrical connection 2, used connections/cores | 25 | ||
| Electrical connection 2, connector system | Sub-D | ||
| Electrical connection 2, connection type | Socket | ||
| Electrical connection 2, function | Controller side | ||
| Electrical connection 1, type of mounting | 2x screw 4-40 UNC | ||
| Electrical connection 1, number of connections/cores | 25 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Angular | ||
| Electrical connection | 25-pin Straight plug Sub-D/Sub-D |
| Cable sheath colour | grey | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| Ambient temperature | 0 °C ... 70 °C | ||
| Degree of protection | IP40 | ||
| Cable diameter | 7 mm | ||
| Cable length | 5 m | ||
| Nominal operating voltage DC | 24 V | ||
| electrical connection 2, type of mounting | 2x screw 4-40 UNC | ||
| Electrical connection 2, number of connections/cores | 25 | ||
| Electrical connection 2, cable outlet | Straight | ||
| Electrical connection 2, design | Angular | ||
| Electrical connection 1, connection pattern | 00995643 | ||
| Electrical connection 1, used connections/cores | 25 | ||
| Electrical connection 1, connector system | Sub-D | ||
| Electrical connection 1, connection type | Plugs | ||
| Electrical connection 1, function | Field device side | ||
| Cable designation | Without inscription label holder |
