| r - Fillet Radius Housing (Max) | 11.20 | mm | |
| T - Bearing Width | 104.775 |
| R - Fillet Radius Shaft (Max) | 1.50 | mm | |
| D - Bearing O.D. | 482.60 | mm |
| Weight | 98.30 | Kg | |
| Bearing Type | Thrust Tapered Roller Bearings - TTHD |
| Bearing Configuration | Thrust TTHD - with cage and I.D. corner reliefs | ||
| d - Bore Diameter | 9 | in |
