| oil content of compressed air max. | 1 mg/m³ | ||
| Medium | compressed air | ||
| min. medium temperature | 5 °c | ||
| min. ambient temperature | 5 °c | ||
| working pressure min. | 2 bar | ||
| repetitive precision | 3 ° | ||
| theoretical torque | 35 nm | ||
| max. permissible axial bearing load | 147 n | ||
| maximum operating frequency | 60 | ||
| theoretical torque at | 6 bar | ||
| Type | single vane | ||
| axis geometry | single | ||
| compressed air connection | g 3/8 |
| oil content of compressed air min. | 0 mg/m³ | ||
| max. medium temperature | 60 °c | ||
| max. ambient temperature | 60 °c | ||
| working pressure max | 10 bar | ||
| angle of rotation max. | 180 ° | ||
| permissible kinetic energy | 1.08 j | ||
| max. permissible radial bearing load | 1960 n | ||
| interior volume | 283 cm³ | ||
| min. swivel times | 0.32 s | ||
| axis diameter | 25 mm | ||
| frame size | rak - 8s | ||
| rotary compact module version | rotary wing drive, double-acting |
