REXROTH R061108010 standard linear bushing

Name: R061108010 REXROTH
Brand: REXROTH
SKU: 290923-en-gbp
Price: 633.35 GBP
Availability: InStock

KBM-E-80-D

£633.35

available with 7 to 15 days delivery to United States

Specifications

Rugged all-metal design with steel ball retainer for harsh environments and heavy contamination
Many pockets acting as lubricant reservoirs for extended lubrication intervals or lubrication for life
For use in woodworking, foundries, cement plants
Stainless steel for the medical, chemistry and food industries
Integrated wiper seals

Type (KB)	Standard linear bushings adjustable, with one wiper seal, R0611
Series (M)	Standard (metal)
Form (E)	Adjustable

Shaft diameter (80)	80 Shaft diameter
Seals (D)	One seal

a_max	50	m/s²
m	4.70	kg
Breakaway force (One wiper seal: Multiply by a factor of 0.5.)	45	N
Rows of balls	6
Shaft radial clearance h6/bore K7	+ 46 - 1
Permissible ambient temperature (min ... max) (Only unsealed Linear Bushings with steel ball retainers may be used at higher temperatures. Make allowance for reductions in load capacity. )	-10 °C ... +80 °C

v_max	2	m/s
F_R (One wiper seal: Multiply by a factor of 0.5.,Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	15	N
m (Friction coefficients of unsealed Linear Bushings when lubricated with oil. The friction coefficient is lowest under heavy load, but can still be above the specified value even under a low load. )	0,001 ... 0,004
Shaft radial clearance h6/bore H7	+ 71 + 24
Operating conditions	Operating conditions
