R106620800 Bosch Rexroth

REXROTH R106620800 linear-set

LSGE-M-8-DD

£74.26
available with 7 to 15 days delivery to United States

Specifications

  • Lightweight precision housing (aluminum)
  • Standard Linear Bushing
  • Secured by grooved taper pin
  • External seals
  • No lube port

Type (LSG) Linear sets Adjustable, R1066
Form (E) Adjustable
Series (M) Standard linear bushing
Shaft diameter (8) 8 Shaft diameter
Seals (DD) With two seals
E1 25 mm ±0.15
H 15 mm
A (Tolerance ISO 8062-3 - DCTG 9.) 32 mm
B (Tolerance ISO 8062-3 - DCTG 9.) 28
Tolerance for H (Clamped (fastened) in relation to Ø d.) + 6
- 17
L 25 mm
SW 2
E2 20 mm ±0.15
D 16 mm
A1 (Tolerance ISO 8062-3 - DCTG 9.) 16 mm
B1 14 mm
H1 (Tolerance ISO 8062-3 - DCTG 9.) 28 mm
S 3.40
V (Tolerance ISO 8062-3 - DCTG 9.) 5 mm
amax 100 m/s²
m 0.09 kg
Breakaway force 1 N
Operating conditions Operating conditions
vmax 2.50 m/s
FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) 0.50 N
Radial clearance Comes clamped to h5 shaft (lower limit) and set to zero clearance
Permissible ambient temperature (min ... max) -10 °C ... +80 °C
