REXROTH R107222000 linear-set

Name: R107222000 REXROTH
Brand: REXROTH
SKU: 433557-en-gbp
Price: 161.26 GBP
Availability: InStock

LSASE-M-20-DD

£161.26

available with 7 to 15 days delivery to United States

Specifications

Type (LSAS)	Linear sets Side opening, adjustable, R1072
Form (E)	Adjustable
Series (M)	Standard linear bushing

Shaft diameter (20)	20 Shaft diameter
Seals (DD)	With two seals

A	60	mm
E₂	30 mm ±0.15
E₄	42	mm
Tolerance for H (Clamped (fastened) in relation to Ø d.)	+ 5 - 19
H₄	22	mm
m (Clamped (fastened) in relation to Ø d.)	17 mm ±0.01
N₂	15	mm
S₁	M10
SW	2.50
W (Minimum size in relation to Ø d.)	10	mm

v_max	2.50	m/s
F_R (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	6	N
Radial clearance	Comes clamped to h5 shaft (lower limit) and set to zero clearance
Permissible ambient temperature (min ... max)	-10 °C ... +80 °C
