FESTO 542184 branching module

Name: 542184 FESTO
Brand: FESTO
SKU: 676890-en-gbp
Price: 235.96 GBP
Availability: InStock

FRM-Y-D-MINI

£235.96

10 pcs. with 1 to 3 days delivery to United States

Specifications

Series (FRM)	Branching module
Additional function (Y)	Pressure switch, connection A1
Pneumatic connection	None

Version (D)	D series, metal
Size (MINI)	Grid dimension 40 mm (without connecting plates)

Material housing		Die-cast aluminium
Pneumatic connection, port 4		G1/4
Product weight		507 g
Media temperature		-10 °C ... 60 °C
Storage temperature		-10 °C ... 60 °C
Operating medium		Compressed air to ISO 8573-1:2010 [7:-:-] Inert gases
Standard nominal flow rate in main flow direction 1->2		3.300 l/min
Symbol		00991510
Mounting position		optional

Note on materials		RoHS-compliant
Pneumatic connection, port 3		G1/4
Ambient temperature		-10 °C ... 60 °C
Air purity class at output		Compressed air to ISO 8573-1:2010 [7:-:-] Inert gases
Corrosion resistance class CRC		2 - Moderate corrosion stress
Operational voltage range DC		0 V ... 125 V
Operating pressure		0 bar ... 12 bar
Design		Branching module
