| Material housing | Wrought aluminium alloy Smooth anodised | ||
| Material drive shaft | High-alloy stainless steel | ||
| Pneumatic connection | M5 | ||
| Permissible mass moment of inertia | 0,008 kgm² ... 0,03 kgm² | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Mode of operation | Double-acting | ||
| Symbol | 00991265 | ||
| Max. number of intermediate positions | 1 | ||
| Mounting position | optional | ||
| Swivel angle | 180 deg |
| Material seals | NBR TPE-U(PU) | ||
| Note on materials | RoHS-compliant | ||
| Type of mounting | With through-hole Via female thread Either: | ||
| Theoretical torque at 0.6 MPa (6 bar, 87 psi) | 0,8 Nm | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Operating pressure | 2 bar ... 10 bar | ||
| Position detection | Via proximity switch | ||
| Design | Rack and pinion | ||
| Cushioning | Elastic cushioning rings/plates at both ends External hydraulic cushioning Internal hydraulic cushioning normal | ||
| Size | 12 |
