FESTO 526262 pressure regulator

Name: 526262 FESTO
Brand: FESTO
SKU: 687830-en-gbp
Price: 56.76 GBP
Availability: InStock

LR-M5-D-O-7-MICRO

£56.76

available with 3 to 7 days delivery to United States

Specifications

Pneumatic connection	M5
Weight	80g

Material membrane		NBR
Material seals		NBR
Note on materials		RoHS-compliant
Pneumatic connection, port 1		M5
Product weight		80 g
Media temperature		-10 °C ... 60 °C
Operating medium		Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases
Max. pressure hysteresis		0,3 bar
Operating pressure		1 bar ... 10 bar
Symbol		00991540
Design		Directly actuated diaphragm regulator
Actuator lock		Rotary knob with detent
Size		Micro

Material housing		Wrought aluminium alloy
Material sub-base		Wrought aluminium alloy
Pneumatic connection, port 2		M5
Type of mounting		In-line installation With accessories Either:
Ambient temperature		-10 °C ... 60 °C
Air purity class at output		Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases
Standard nominal flow rate		120 l/min
Pressure regulation range		0,5 bar ... 7 bar
Pressure gauge (ANALOG) or Pressure display (DIGITAL)		M5 prepared
Controller function		With secondary venting
Mounting position		optional
Series		D
