| Material screws | Coated steel | ||
| Material adapter | Epoxy resin | ||
| Product weight | 80,2 g | ||
| Tolerance for tightening torque | ±10% | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Operating pressure | 14,5 psi ... 116 psi | ||
| Size | 20 |
| Material seals | FPM | ||
| Pneumatic connection | G1/8 | ||
| Max. tightening torque pneumatic connection 1 | 3 Nm | ||
| Max. tightening torque | 3 Nm | ||
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Stroke | 200 mm |
