| Material housing | PA-reinforced | ||
| Switching logic for inputs | PNP (positive switching) | ||
| Product weight | 167 g | ||
| Degree of protection | IP20 | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress (when installed) | ||
| Switching level | Signal 0: <= 5 V Signal 1: ≥ 15 V | ||
| Isolation channel - internal bus | no | ||
| Max. residual current of inputs per module | 1,8 A | ||
| Operational voltage range DC | 18 V ... 30 V | ||
| Input debounce time | 3 ms (0.1 ms, 10 ms, 20 ms, parameterisable) | ||
| Parameterisation | Input debounce time Signal extension time Behaviour after short circuit Module monitoring | ||
| Number of inputs | 16 |
| Note on materials | RoHS-compliant | ||
| Characteristic for inputs | IEC1131-T2, type 01 | ||
| Ambient temperature | -5 °C ... 50 °C | ||
| Storage temperature | -20 °C ... 70 °C | ||
| Approval | c UL us listed (OL) | ||
| Isolation channel - channel | no | ||
| Nominal operating voltage DC | 24 V | ||
| Intern power consumption nominal operating voltage | Typ. 15 mA | ||
| Fuse protection (short circuit) | Internal electronic fuse per module | ||
| LED display | 1 Group diagnostics 16 Channel status | ||
| Diagnosis | Short circuit/overload per channel | ||
| Dimensions (W x L x H) | (incl. interlinking block) 50 x 107 x 41 mm |
