| Material membrane | PUR | ||
| Material seals | NBR | ||
| Pneumatic connection, port 5 | G1/4 | ||
| Pneumatic connection, port 3 | G1/4 | ||
| Pneumatic connection, port 1 | G1/4 | ||
| Pilot air port 12 | G1/8 | ||
| Media temperature | -10 °C ... 60 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Max. switching frequency | 40 Hz | ||
| Type of piloting | Pilot actuated | ||
| Mounting position | optional | ||
| Type of reset | Pneumatic spring | ||
| pneumatic working port | Sub-base | ||
| Type of actuation | Electric |
| Material housing | Wrought aluminium alloy | ||
| Note on materials | Contains paint-wetting impairment substances | ||
| Pneumatic connection, port 4 | G1/4 | ||
| Pneumatic connection, port 2 | G1/4 | ||
| Pilot air port 14 | G1/8 | ||
| Type of mounting | On sub-base | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Switching time on | 28 ms | ||
| Symbol | 00991049 | ||
| Manual override | Non-detenting | ||
| Nominal size | 6,5 mm | ||
| Operating pressure | 1,5 bar ... 10 bar | ||
| Standard nominal flow rate | 1.400 l/min | ||
| Valve function | 5/2-way, monostable |
