| number of poles | three-pole | ||
| operation | non-reversing | ||
| continuous ampere rating | 15 a | ||
| Type | full voltage non-reversing contactor | ||
| coil voltage | 24 vdc | ||
| frame size | 45 mm | ||
| certifications | ul listed csa certified iec 60947 en 60947 |
||
| product height | 2 in | ||
| UPC | 786689005313 |
| amperage rating | 15a | ||
| terminals | screw terminals | ||
| hp rating - max | 1, 2, 3/ 5, 5, 10, 10 hp (1/3ph @115,200,230/200,230,460,575 v) | ||
| Series | xt iec | ||
| contact configuration | 1 no | ||
| catalog notes | screw terminals (6-65a); 5 mm (80-150a); no lugs (185-2000a) | ||
| compliances | ce marked rohs compliant |
||
| ean | 4015082900731 |
