| Material supply plate | PA-reinforced | ||
| Pneumatic connection, port 1 | QS-6 | ||
| Ambient temperature | -5 °C ... 50 °C | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Pilot pressure | 3 bar ... 8 bar | ||
| Symbol | 00991883 |
| Note on materials | RoHS-compliant | ||
| Product weight | 35 g | ||
| LABS (PWIS) conformity | VDMA24364-B1/B2-L | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Operating pressure | -0,9 bar ... 10 bar | ||
| Grid dimension | 14 mm |
