| Material manifold | Wrought aluminium alloy | ||
| Pneumatic connection, port 3 | G1/8 | ||
| Product weight | 96 g | ||
| Max. tightening torque for valve mounting | 0,45 Nm | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating pressure | -0,9 bar ... 10 bar | ||
| Grid dimension | 10,5 mm |
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | G1/8 | ||
| Max. tightening torque wall mounting | 3 Nm | ||
| Max. tightening torque H-rail mounting | 1,5 Nm | ||
| Approval | RCM trademark c UL us - Recognized (OL) | ||
| Max. number of valve positions | 16 |
