| Dimension A4 | 28.30 | mm | |
| Inner Ring Width B | 31 | mm | |
| Center of Bearing from Housing End A2 | 10 | mm | |
| Bolt Hole Size N | 12 | mm | |
| Bolt Circle Diameter J | 78 | mm | |
| Total Height L | 100 | mm |
| Center of Bearing from Bearing End S | 12.70 | mm | |
| Pilot Width A3 | 5 | mm | |
| Flange Width A1 | 20.50 | mm | |
| Bolt Hole Spacing J1 | 55.10 | mm | |
| Pilot Outside Diameter H3 | 62 | mm |
| Weight | 0.70 | Kg | |
| Locking Style | Set Screw Locking | ||
| Shaft Size d | 20 | mm |
| Housing Construction | Round Flange | ||
| UPC Code | 87,796,076,013 | ||
| Bearing Number | UC204 |
