| Note on materials | Contains paint-wetting impairment substances | ||
| Pneumatic connection, port 2 | PK-3 | ||
| Type of mounting | With through-hole | ||
| Media temperature | -10 °C ... 80 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Flow direction | Non-reversible | ||
| Mounting position | optional | ||
| Nominal size | 1,5 mm | ||
| Design | Ball seat | ||
| pneumatic working port | PK-3 | ||
| Type of actuation | Mechanical |
| Pneumatic connection, port 3 | Not ducted | ||
| Pneumatic connection, port 1 | PK-3 | ||
| Ambient temperature | -10 °C ... 80 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Symbol | 00991097 | ||
| Type of piloting | Direct | ||
| Sealing principle | Soft | ||
| Type of reset | Mechanical spring | ||
| Operating pressure | -0,9 bar ... 8 bar | ||
| Standard nominal flow rate | 50 l/min | ||
| Valve function | 3/2-way, closed, monostable |
