| Bore diameter | d | 60 | mm |
| Width Inner ring | B | 44 | mm |
| Width head | C1 | max.50.5 | |
| Angle of tilt | α | 6 | ° |
| Housing diameter shank | d3 | max.76.5 | |
| Length (height) housing | l4 | max.202.5 | |
| Width shank | N | max.120 | |
| Chamfer dimension bore | r1 | min.1 |
| Diameter head | d2 | max.132 | |
| Thread | M 58x1.5 | ||
| Height shank end face - centre rod end eye | h1 | 130 | mm |
| Raceway diameter inner ring | F | 80 | mm |
| Length threat | l3 | min.59 | |
| Distance shank chamfer - centre rod end eye | l7 | min.64 | |
| Thickness shank base for clamping bolts | N1 | max.47 |
