| Selection of sensor design | Standard | ||
| Additional information for sensor selection | with standard sensing distance | ||
| Corrosion resistance class CRC | 4 - Very high corrosion stress | ||
| Degree of protection | IP67 | ||
| Switching status indication | Yellow LED | ||
| Product weight | 33,6 g | ||
| Tightening torque | 1,5 Nm | ||
| Material cable sheath | TPE-U(PUR) | ||
| Electrical connection | 3-wire Cable | ||
| Operational voltage range DC | 10 V ... 30 V | ||
| Max. output current | 200 mA | ||
| Switching element function | N/O contact | ||
| Repetition accuracy with constant conditions | 0.01 mm | ||
| Rated operating distance | 0,8 mm | ||
| CE mark (see declaration of conformity) | To EU EMC Directive | ||
| Symbol | 00991702 |
| Electrical output | PNP | ||
| Pollution degree | 3 | ||
| Immunity to surge | 1 kV | ||
| Ambient temperature with moving cable | -5 °C ... 70 °C | ||
| Material housing | PA High-alloy stainless steel | ||
| Mounting type | Flush | ||
| Size | M5x0.5 | ||
| Cable length | 2,5 m | ||
| Reverse polarity protection | For all electrical connections | ||
| Short circuit current rating | Pulsed | ||
| Max. switching frequency | 5.000 Hz | ||
| Switching output | PNP | ||
| Ambient temperature | -25 °C ... 70 °C | ||
| Note on materials | RoHS-compliant | ||
| Approval | RCM trademark c UL us listed (OL) | ||
| Conforms to standard | EN 60947-5-2 |
