| Material seals | NBR | ||
| Sound pressure level | 83 dB(A) | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Mounting position | optional | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Ambient temperature | -20 °C ... 75 °C | ||
| Standard nominal flow rate, air flow 0.6->0,5 MPa (6->5 bar, 87->72.5 psi) | 2.880 l/min | ||
| Standard nominal flow rate, exhaust 0.6->0.5 MPa (6->5 bar, 87->72.5 psi) | 2.280 l/min | ||
| Pneumatic connection, port 2 | G3/8 | ||
| Selection of additional functions | With silencer |
| Product weight | 160 g | ||
| Media temperature | -20 °C ... 75 °C | ||
| Symbol | 00991460 | ||
| Nominal size | 11 mm | ||
| Material housing | Die-cast aluminium | ||
| Operating pressure | 0,2 bar ... 10 bar | ||
| Standard nominal flow rate, exhaust 0.6->0 MPa (6->0 bar, 87->0 psi) | 4.680 l/min | ||
| Type of mounting | Screw-in | ||
| Pneumatic connection, port 1 | G3/8 | ||
| Valve function | Quick exhaust |
