| Valve function | Quick exhaust | ||
| Pneumatic connection, port 2 | G3/4 | ||
| Standard nominal flow rate, exhaust 0.6->0.5 MPa (6->5 bar, 87->72.5 psi) | 7.500 l/min | ||
| Operating pressure | 0,5 bar ... 10 bar | ||
| Material housing | Wrought aluminium alloy Anodised | ||
| Nominal size | 19 mm | ||
| Symbol | 991,459 | ||
| Media temperature | -20 °C ... 75 °C | ||
| Pneumatic connection, port 3 | G3/4 | ||
| Material seals | NBR |
| Pneumatic connection, port 1 | G3/4 | ||
| Type of mounting | With through-hole | ||
| Standard nominal flow rate, air flow 0.6->0,5 MPa (6->5 bar, 87->72.5 psi) | 2.500 l/min | ||
| Ambient temperature | -20 °C ... 75 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Mounting position | optional | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Product weight | 710 g | ||
| Note on materials | RoHS-compliant |
