| data performance b10 value number of cycles | 5000000 | ||
| flow flow dm3sec | 105 dm3/sec | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 145 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 10 bar | ||
| range | r74m | ||
| Series | excelon |
| data performance shelf life | 3 years | ||
| flow flow dm3secbar | 105 dm3/(s.bar) dm3/sec | ||
| gauge port | 1/8" nptf | ||
| maximum inlet pressure pressure bar | 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 175 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 145 psi | ||
| Port size | g1/2 | ||
| retrieve price | true |
