| Material cable sheath | polyurethane | ||
| Weight | 1.491 kg | ||
| wire cross-section | 0.22 mm² | ||
| max. ambient temperature | 80 °c | ||
| Protection class | ip67 | ||
| suitable for dynamic laying | suitable for dynamic laying | ||
| Shielding | unshielded | ||
| Electrical connection 2 | 25-pin | ||
| cable exit | straight | ||
| operating voltage ac max. | 24 v dc | ||
| Type | multipole |
| Housing Material | thermoplastic elastomer | ||
| cable-Ø | 10.5 mm | ||
| max. current | 3 a | ||
| min. ambient temperature | -20 °c | ||
| bending radius min. | 78.75 mm | ||
| Cable length | 10 m | ||
| number of wires | 25 | ||
| cable exit angle | 180° | ||
| Electrical connection 1 | 25-pin | ||
| cable | with cable |
