| min. detection distance | 0.01 mm | ||
| Protection class | ip67 | ||
| dc operating voltage | 24 v | ||
| oil content of compressed air max. | 0.1 mg/m³ | ||
| max. particle size | 5 µm | ||
| max. medium temperature | 50 °c | ||
| max. ambient temperature | 50 °c | ||
| working pressure max | 3.3 bar | ||
| compressed air connection | base plate din iso 15407-1 | ||
| Grid dimension | 27 mm | ||
| Type | ms01 test module |
| Duty cycle | 100 % | ||
| voltage tolerance dc | -10% / +10% | ||
| cleaning pressure max. | 10 bar | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| Medium | compressed air | ||
| min. medium temperature | 0 °c | ||
| min. ambient temperature | 0 °c | ||
| working pressure min. | 2.7 bar | ||
| certificates | ce declaration of conformity | ||
| Electrical connection | 5-pin | ||
| Standards | 26 mm |
