| adjusting knob | acetal resin | ||
| air pilot ports | g1/4 | ||
| bonnet | zinc alloy | ||
| gauge | no gauge | ||
| inner parts | synthetic rubber | ||
| maximum inlet pressure pressure bar | 20 bar | ||
| operating temperature f temperature fahrenheit min to max range | 0 ... 175 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 10 ... 246 psi | ||
| Port size | g1/4 | ||
| range | r24 |
| Adjustment | knob | ||
| body | zinc alloy | ||
| elastomers | nitrile rubber | ||
| gauge port | g1/4 | ||
| maximum inlet pressure imperial pressure psi | 290 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | 0 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.7 ... 17 bar | ||
| product style | ported | ||
| relievingnonrelieving | relieving |
