| adjusting screw | stainless steel | ||
| body | stainless steel | ||
| brochure | z7844br_f22-imi-pe_en_lr.pdf | ||
| elastomers | synthetic rubber | ||
| flow flow dm3secbar | 50 dm3/(s.bar) dm3/sec | ||
| gauge port | 1/4" nptf | ||
| maximum inlet pressure pressure bar | 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 175 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 145 psi | ||
| port connections | 1/2" nptf | ||
| product style | ported | ||
| relievingnonrelieving | relieving | ||
| Standard | nace mr-0175, 2002 revision |
| Adjustment | t-bar | ||
| bonnet | stainless steel | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 50 dm3/sec | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 145 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 10 bar | ||
| Port size | 1/2" ptf | ||
| range | r22 | ||
| Series | stainless steel |
