| air pilot ports | g1/4 | ||
| bonnet | aluminium alloy | ||
| flow flow dm3sec | 950 dm3/sec | ||
| gauge | no gauge | ||
| inner parts | aluminium | ||
| maximum inlet pressure pressure bar | 31 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 175 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 10 ... 246 psi | ||
| Port size | g2 | ||
| relievingnonrelieving | relieving |
| body | aluminium | ||
| elastomers | nitrile rubber | ||
| flow flow dm3secbar | 950 dm3/(s.bar) dm3/sec | ||
| gauge port | g1/4 | ||
| maximum inlet pressure imperial pressure psi | 450 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.7 ... 17 bar | ||
| range | r18 |
