1)
Size -040
2)
Size from -065
3)
Type 1
4)
Type 2
5)
Type 3
| Size | MKK-/MKR-165 | ||
| B | 29 | ||
| D | 40.50 | mm | |
| F | 41 | mm | |
| H | 13 | mm |
| A | 163 | mm | |
| C | 105 | mm | |
| e | 27 | ||
| Thread (Countersink ISO 4762) | M10 | ||
| Number of holes | 2 | N |
| Size | MKK-/MKR-165 |
| MA (for friction factor 0.125, as per strength class 8.8) | 46 | Nm |
