1)
Bore 6.6 mm for screws M6 ISO 4762, number N
2)
Type 1
3)
Type 2
4)
Type 3
| Size | MKR-080 | ||
| B | - | ||
| D | 11.50 | mm | |
| Thread (Countersink ISO 4762) | M6 | ||
| Number of holes | 1 | N |
| A | 25 | mm | |
| C | - | ||
| F | 19.30 | mm | |
| H | 7.50 | mm |
| Size | MKR-080 |
| MA (as per strength class 8.8) | 9.50 | Nm |
