| adjusting knob | acetal resin | ||
| body | zinc | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 7 dm3/sec | ||
| flow imperial flow scfm | 15 scfm | ||
| gauge port | 1/8" npt | ||
| maximum inlet pressure imperial pressure psi | 10 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 65 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.1 ... 0.7 bar | ||
| product style | ported | ||
| relievingnonrelieving | relieving |
| Adjustment | knob | ||
| bonnet | acetal | ||
| elastomers | nitrile rubber | ||
| flow flow dm3secbar | 7 dm3/(s.bar) dm3/sec | ||
| gauge | external gauge | ||
| inner parts | brass | ||
| maximum inlet pressure pressure bar | 0.7 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 149 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 1 ... 10 psi | ||
| Port size | 1/4" ptf | ||
| range | r07 | ||
| Series | 07 series |
