| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Setting range threshold value | 1,5 bar ... 8 bar | ||
| Material housing | PA PET POM | ||
| Pneumatic connection | M5 | ||
| Type of mounting | With through-hole With H-rail Either: | ||
| Operational voltage range DC | 10 V ... 30 V | ||
| Max. switching frequency | 3 Hz | ||
| Switching element function | Changeover switch | ||
| Media temperature | 0 °C ... 60 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Pressure measuring range | 2 bar ... 8 bar | ||
| Measured variable | Relative pressure | ||
| CE mark (see declaration of conformity) | To EU EMC Directive | ||
| Symbol | 00991472 |
| Degree of protection | IP65 | ||
| Switching status indication | Yellow LED | ||
| Product weight | 56 g | ||
| Mounting position | optional | ||
| Electrical connection | 4-pin M8x1 Plugs | ||
| Max. output current | 2.500 mA | ||
| Hysteresis | 0,5 bar ... 2 bar | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Operating pressure | 0 bar ... 8 bar | ||
| Measurement method | Pneumatic/electric pressure transducer | ||
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant | ||
| Approval | RCM trademark |
