| Material seals | NBR | ||
| Pneumatic connection, port 3 | PK-3 | ||
| Media temperature | -10 °C ... 60 °C | ||
| Symbol | 00991102 | ||
| Nominal size | 2,4 mm | ||
| Material housing | POM | ||
| Operating pressure | 1,6 bar ... 8 bar | ||
| Type of mounting | With through-hole | ||
| Pneumatic connection, port 1 | PK-3 |
| Note on materials | RoHS-compliant | ||
| Product weight | 9 g | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Mounting position | optional | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Standard nominal flow rate | 120 l/min | ||
| Pneumatic connection, port 2 | PK-3 | ||
| Valve function | OR function |
