| Material electrical contact | Nickel-plated and gold-plated bronze | ||
| Material housing | PA | ||
| Pollution degree | 2 | ||
| CE marking (see declaration of conformity) | To UK instructions for EMC | ||
| Storage temperature | -40 °C ... 80 °C | ||
| Note on degree of protection | In assembled state | ||
| Shielding | no | ||
| Operational voltage range DC | 0 V ... 310 V | ||
| Electrical connection 3, type of mounting | Plug-in | ||
| Electrical connection 3, number of connections/cores | 3 | ||
| Electrical connection 3, connection type | Plugs | ||
| Electrical connection 3, function | Controller side | ||
| Electrical connection 2, used connections/cores | 3 | ||
| Electrical connection 2, connector system | ZIF | ||
| Electrical connection 2, design | Angular | ||
| Electrical connection 1, type of mounting | Plug-in | ||
| Electrical connection 1, number of connections/cores | 12 | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side | ||
| Cable outlet | Straight | ||
| Dimensions (W x L x H) | 18.7 x 50 x 15.3 mm |
| Housing colour | Black | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Degree of protection | IP40 | ||
| Protective conductor connection | Not available | ||
| Electrical connection 3, connection pattern | 00997358 | ||
| Electrical connection 3, used connections/cores | 3 | ||
| Electrical connection 3, connector system | Festo-specific coding | ||
| Electrical connection 3, design | Rectangular | ||
| electrical connection 2, type of mounting | Plug-in | ||
| Electrical connection 2, number of connections/cores | 12 | ||
| Electrical connection 2, connection type | Socket | ||
| Electrical connection 2, function | Field device side | ||
| Electrical connection 1, used connections/cores | 3 | ||
| Electrical connection 1, connector system | ZIF | ||
| Electrical connection 1, design | Angular | ||
| Product weight | 6,8 g | ||
| Type of mounting | Via through-hole for M3 screw |
