| Dimensions (W x L x H) | 50 x 45 x 19.6 mm | ||
| Material housing | PA6 reinforced | ||
| USB interface, connection technology | USB 2.0 type B mini | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Relative air humidity | Non-condensing Max. 95% at 60°C | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| CE mark (see declaration of conformity) | To EU EMC Directive In accordance with EU RoHS Directive | ||
| Approval | RCM trademark | ||
| Operational voltage range DC | 4,5 V ... 5,5 V | ||
| Display characteristics | Touchscreen | ||
| User memory | 3 GB |
| Area of application | Only with CMMT, CPX-E-CEC | ||
| Note on materials | RoHS-compliant | ||
| Product weight | 36,6 g | ||
| Degree of protection | IP20 | ||
| Storage temperature | -20 °C ... 70 °C | ||
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions | ||
| KC mark | KC-EMV | ||
| Display resolution | 128x160 pixels | ||
| Display size | 1.77" | ||
| Display | Colour TFT | ||
| Max. cable length | 3 m |
