| Housing colour | Black | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Ambient temperature | -40 °C ... 115 °C | ||
| Degree of protection | IP20 | ||
| Shielding | no | ||
| Current rating at 40°C | 8 A | ||
| Electrical connection 2, connector system | Spring-loaded terminal | ||
| Electrical connection 1, type of mounting | Plug-in | ||
| Electrical connection 1, connector system | Connection pattern L8 | ||
| Electrical connection 1, design | Angular | ||
| Product weight | 3,8 g |
| Material housing | PA | ||
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant | ||
| Note on degree of protection | In assembled state | ||
| Conductor nominal cross section | AWG28 - 16 | ||
| Immunity to surge | 1,6 kV | ||
| Operational voltage range DC | 0 V ... 300 V | ||
| Electrical connection 1, connection pattern | 00997297 | ||
| Electrical connection 1, number of connections/cores | 5 | ||
| Electrical connection 1, connection type | Socket | ||
| Size of pack | 1 | ||
| Cable outlet | Straight |
