| Brand | ntn | ||
| Da max - Max shoulder diameter OR | 158,5 mm | ||
| Tmax - Max operating temperature | 120 °C | ||
| N lim - Oil lubrication limit speed | 3000 tr/min | ||
| C0r - Static load rating | 380 kN | ||
| mass | 2,84 kg | ||
| Lubrication hole on inner ring | Non/No | ||
| Lubrication hole on outer ring | Oui/Yes | ||
| rs - Min fillet radius | 1,1 mm | ||
| C - Width of bearing, drawn cup or outer ring | 45 mm | ||
| d - Internal diameter | 120 mm |
| ras max - Max shaft & housing fillet radius | 1 mm | ||
| da min - Min shoulder diameter IR | 126,5 mm | ||
| Tmin - Min operating temperature | -20 °C | ||
| N lim - Grease lubrication limit speed | 2000 tr/min | ||
| Cr - Dynamic load rating | 180 kN | ||
| Radial clearance class | C3 | ||
| k - Hole diameter | 3,5 mm | ||
| s - Max axial offset | 2 mm | ||
| F - Under roller diameter | 135 mm | ||
| D - External diameter | 165 mm |
