| Material seals | NBR | ||
| Material housing | Polymer | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| CE mark (see declaration of conformity) | To EU Low Voltage Directive In accordance with EU RoHS Directive | ||
| Note on degree of protection | In assembled state | ||
| Connection cross section | 0,75 mm² | ||
| Permissible cable diameter | 7,5 mm | ||
| Cable fitting | Pg7 | ||
| Immunity to surge | 4 kV | ||
| Current rating at 40°C | 6 A | ||
| Operational voltage range DC | 0 V ... 300 V | ||
| Electrical connection 1, connection pattern | 00995650 | ||
| Electrical connection 1, cable outlet | Angled | ||
| Electrical connection 1, design | Angular | ||
| Product weight | 11 g | ||
| Note on cable outlet | 90° rotatable | ||
| Type of mounting | On solenoid valve via M2.5 central screw |
| Housing colour | Black | ||
| Pollution degree | 3 | ||
| CE marking (see declaration of conformity) | To UK regulations for electrical equipment To UK RoHS instructions | ||
| Ambient temperature | -45 °C ... 90 °C | ||
| Degree of protection | IP65 To IEC 60529 | ||
| Nominal cross section conductor | ≤ 0,75 mm² | ||
| Cable diameter | 6 mm ... 8 mm | ||
| Protective conductor connection | Available | ||
| Permissible current load | 6 A | ||
| Operational voltage range AC | 0 V ... 250 V | ||
| Electrical connection 2 | Screw terminal | ||
| Electrical connection 1, number of connections/cores | 3 | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection | 3-pin Socket Angled socket Type C To DIN EN 175301-803 To DIN EN 61984 Square design MSEB Square design MSN2 | ||
| Mounting position | optional | ||
| Cable outlet | Angled |
