| Mounting position | optional | ||
| Min. pick-up time | 10 ms | ||
| Power factor (cos phi) | 0,7 | ||
| Permissible frequency fluctuations | +/- 5% | ||
| CE mark (see declaration of conformity) | To EU Low Voltage Directive | ||
| LABS (PWIS) conformity | VDMA24364-C1-L | ||
| Ambient temperature | -5 °C ... 40 °C | ||
| Product weight | 55 g | ||
| Type of mounting | Via knurled nut | ||
| Material solenoid coil | Duroplast Copper Steel |
| Switching position indicator | no | ||
| Duty cycle | 100% | ||
| Characteristic coil data | 110 V AC: 50/60 Hz, pick-up power 9.0 VA, holding power 7.0 VA | ||
| Permissible voltage fluctuations | +/- 10 % | ||
| CE marking (see declaration of conformity) | To UK regulations for electrical equipment | ||
| Degree of protection | IP65 | ||
| Max. tightening torque for socket | 0,4 Nm | ||
| Electrical connection | 3-pin Plug pins with connection pattern to Festo standard for MSSD-F | ||
| Note on materials | RoHS-compliant | ||
| Material winding | Copper |
