| Bore diameter | d | 80 | mm |
| Nominal width | B | 50 | mm |
| Raceway diameter inner ring (sphere diameter shaft washer) | dk | 197 | mm |
| Bore diameter outer ring (housing washer) | D1 | 107.50 | mm |
| Height outer ring (housing washer) | C | 38 | mm |
| Distance sphere diameter centre - shaft washer back face (large inner ring side face) | s | 42.50 | mm |
| Outside diameter | d2 | 180 | mm |
| Angle of tilt | α | 3.90 | ° |
| Outside diameter inner ring (shaft washer) | d1 | 172 | mm |
| Height inner ring (shaft washer) | B | 43.50 | mm |
| chamfer dimension | rmin | min.1 |
