| Bore diameter | d | 101.60 | mm |
| Nominal width | B | 88.90 | mm |
| Angle of tilt | α | 6 | ° |
| Width annular lubrication groove at outer ring | b | 11 | mm |
| Diameter lubrication hole (outer ring) | M | 8 | mm |
| Chamfer dimension outer ring | r1,2 | min.1 |
| Outside diameter | d2 | 158.75 | mm |
| Width Outer ring | C | 76.20 | mm |
| Raceway diameter inner ring | F | 146.05 | mm |
| Width annular lubrication groove at inner ring | b1 | 10 | mm |
| Chamfer dimension bore | r1 | min.0.6 |
| Manufacturer | Part Number |
|---|---|
| INA | GE101-ZO |
