| Material housing | Die-cast aluminium | ||
| Pneumatic connection, port 2 | For tubing outside diameter of 6 mm | ||
| Number of supply lines | 1 | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Operating pressure complete temperature range | 0 bar ... 8 bar | ||
| Nominal size | 3,4 mm |
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | Female thread G1/4 | ||
| Number of outputs | 12 | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Mounting position | optional |
