| body | aluminium | ||
| drain type | automatic drain | ||
| filter element | activated carbon and polycarbonate | ||
| flow flow dm3sec | 60 dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 247 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 65 °c | ||
| Port size | g1 | ||
| range | ffv68 |
| data performance shelf life | 3 years | ||
| elastomers | synthetic rubber | ||
| filter element m particlesize micron | 0.01 μm | ||
| flow flow dm3secbar | 60 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 149 °f | ||
| particle removal particlesize micron | 0.01 μm | ||
| product style | plug-in | ||
| Series | olympian plus |
