| Size | 25 | ||
| Reversing backlash theoretical | 0 µm | ||
| Guide | Recirculating ball bearing guide | ||
| Max. acceleration | 25 m/s² | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Ambient temperature | 0 °C ... 50 °C | ||
| Max. force Fy static | 415 N | ||
| Max. force Fz static | 415 N | ||
| Max. torque Mx static | 19 Nm | ||
| Max. torque My static | 12 Nm | ||
| Max. torque Mz static | 12 Nm | ||
| Moving mass for 0 mm stroke | 300 g | ||
| Additional weight per 10 mm stroke | 12 g | ||
| Centre of gravity at 0 mm stroke | 30 mm | ||
| Type of mounting | Via female thread | ||
| Material guide component | Tempered steel Hard-chrome-plated | ||
| Material yoke plate | Wrought aluminium alloy Anodised |
| Stroke | 1 mm ... 300 mm | ||
| Mounting position | optional | ||
| Design | Guidance | ||
| Max. speed | 1 m/s | ||
| Degree of protection | IP40 | ||
| Max. force Fy | 320 N | ||
| Max. force Fz | 320 N | ||
| Max. moment Mx | 15 Nm | ||
| Max. moment My | 10 Nm | ||
| Max. moment Mz | 10 Nm | ||
| Displacement force | 4 N | ||
| Basic weight for 0 mm stroke | 1.080 g | ||
| Additional moving mass per 10 mm stroke | 12 g | ||
| Centre of gravity additional of moving mass per 10 mm | 4,5 mm | ||
| Note on materials | RoHS-compliant | ||
| Material housing | Wrought aluminium alloy Anodised |
