| Material piston rod | High-alloy steel | ||
| Material seals | NBR | ||
| Type of mounting | Via threaded sleeve | ||
| Reset force | 0,5 N | ||
| Max. energy consumption per hour | 4.500 J | ||
| Max. tightening torque | 1 Nm | ||
| Cushioning length | 4 mm | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Reset time at min. ambient temperature | 1 s | ||
| Max. impact speed | 1 m/s | ||
| Position detection | Without | ||
| Cushioning | Self-adjusting | ||
| Size | 3 |
| Material housing | High-alloy steel | ||
| Note on materials | RoHS-compliant | ||
| Product weight | 7,8 g | ||
| Max. residual energy | 0,004 J | ||
| Max. energy consumption per stroke | 0,4 J | ||
| Max. stop force | 80 N | ||
| Ambient temperature | -10 °C ... 80 °C | ||
| Mode of operation | Single-acting Pushing | ||
| Reset time at room temperature | 0,2 s | ||
| Symbol | 00991495 | ||
| Mounting position | optional | ||
| Stroke | 4 mm |
