FESTO 8159473 shock absorber

Name: 8159473 FESTO
Brand: FESTO
SKU: 710287-en-gbp
Price: 18.19 GBP
Availability: InStock

DYEF-G8-S-M8-Y1

£18.19

2 pcs. with 1 to 3 days delivery to United States

Specifications

Geometric characteristics (Y1)	Internal hex
Stop	None
Special material properties	None

Material housing		High-alloy steel
Note on materials		RoHS-compliant
Product weight		14,6 g
Max. tightening torque		2 Nm
Ambient temperature		0 °C ... 60 °C
Corrosion resistance class CRC		2 - Moderate corrosion stress
Position detection		Without
Cushioning		Elastic cushioning rings/pads at both ends without metal fixed stop
Size		M8

Material seals		NBR
Type of mounting		Via threaded sleeve
Max. energy consumption per stroke		0,12 J
Cushioning length		1,3 mm
LABS (PWIS) conformity		VDMA24364-B2-L
Max. impact speed		0,8 m/s
Mounting position		optional
Stroke		1,3 mm
