| Size | 25 | ||
| Swivel angle | 0 deg ... 90 deg | ||
| Mounting position | optional | ||
| Design | Vane | ||
| Symbol | 00991265 | ||
| Operating pressure | 2 bar ... 8 bar | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Suitability for the production of Li-ion batteries | Metals with more than 1% copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickel-plated surfaces, printed circuit boards, cables, electrical plug connectors and coils | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Max. radial force | 60 N | ||
| Permissible mass moment of inertia | 0,012 kgm² | ||
| Type of mounting | Via female thread | ||
| Note on materials | RoHS-compliant | ||
| Material seals | TPE-U(PU) |
| Cushioning angle | 0,5 deg | ||
| Cushioning | Elastic cushioning rings/plates at both ends | ||
| Mode of operation | Double-acting | ||
| Position detection | Via proximity switch | ||
| Variants | Spigot shaft | ||
| Max. swivel frequency at 0.6 MPa (6 bar, 87 psi) | 3 Hz | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| Cleanroom class | Class 6 according to ISO 14644-1 | ||
| Max. axial force | 40 N | ||
| Theoretical torque at 0.6 MPa (6 bar, 87 psi) | 5 Nm | ||
| Product weight | 502 g | ||
| Pneumatic connection | M5 | ||
| Material drive shaft | Nickel-plated steel | ||
| Material housing | Painted die cast aluminium |
