| Material housing | Aluminium | ||
| Pneumatic connection, port 2 | For tubing inside diameter of 9 mm | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation possible | ||
| Maritime classification | See certificate | ||
| Type of seal on screw-in stud | Sealing ring |
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | Male thread G3/8 | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com | ||
| Mounting position | optional | ||
| Nominal size | 8 mm |
