| Note on materials | RoHS-compliant | ||
| Product weight | 2.500 g | ||
| Degree of protection | IP20 | ||
| Storage temperature | -40 °C ... 85 °C | ||
| CE mark (see declaration of conformity) | To EU EMC Directive To EU Low Voltage Directive | ||
| Mains frequency | 45 Hz ... 65 Hz | ||
| Input voltage range AC | 400 V ... 500 V | ||
| Nominal output voltage DC | 48 V | ||
| Primary supply | 3-phase | ||
| Length | 179 mm | ||
| Width | 96 mm |
| Type of mounting | With H-rail | ||
| Ambient temperature | -25 °C ... 70 °C | ||
| Relative air humidity | 95 % | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| Approval | c UL us listed (OL) | ||
| Power failure bridging | 25 ms | ||
| Nominal output current | 20 A | ||
| Input current | 1.7 - 2.1 A | ||
| Mounting position | Free convection | ||
| Height | 130 mm |
