| Tmax - Max operating temperature | 80 °C | ||
| C0max | 10,534 kN | ||
| Cmax | 8,435 kN | ||
| Number of ball rows | 6 | ||
| G | 1,5 mm | ||
| L2 | 2,15 mm | ||
| L1 tolerance | 0/-0,3 | ||
| L - Length tolerance | 0,2/-0,2 | ||
| Re-lubricable | Yes | ||
| Material Cage | PA | ||
| Number of seals | 2 | ||
| Ball bushings category | Super ball bushings, closed | ||
| Brand | SNR |
| Tmin - Min operating temperature | -20 °C | ||
| C0min | 8,23 kN | ||
| Cmin | 6,59 kN | ||
| J | 2,4 mm | ||
| Diameter F H11 | 3 mm | ||
| D1 - Diameter | 59 mm | ||
| L1 | 60,6 mm | ||
| L - Length | 80 mm | ||
| Initial greasing | No | ||
| Material outer cylinder or steel segments | 100Cr6 | ||
| Standard | ISO dimensions | ||
| Design type | BBET |
