| Bore | Tapered 1:30 | ||
| Associated bearing | 240/670 | ||
| Designation of the associated blocking device | MS30/630 | ||
| a - Distance to bore of oil injection hole | 12 mm | ||
| G1 - Designation of tapping holes for oil injection | G1/4 | ||
| G - Thread designation | Tr710X7 | ||
| B1 - Sleeve length | 348 mm |
| Designation of the associated hydraulic nut | HMV142 EBF | ||
| Designation of the nut | HM30/630 | ||
| Designation of the associated nut | HM31/710 | ||
| lG1 - Tapping length of oil injection holes | 15 mm | ||
| lG - Sleeve thread length | 40 mm | ||
| B4 - Overall dismantling length | 374 mm | ||
| Brand | SNR |
